How to Decommission a VMware Host from a Dell (EMC) VxRail vSAN Cluster After Migrating to Azure

By Behan Venter, CTO, Hudson Cloud Systems

Migrating workloads to Azure is a major milestone, but what comes next is just as important. Once your VMs are safely in the cloud, it’s time to clean up your on-prem environment. This post walks through the full process of decommissioning a VMware host from a VxRail vSAN cluster after completing a cloud migration.

We recently completed this task in a production environment, and we’ve broken it down into clear, practical steps you can follow.

⚠️ Warning ⚠️: This procedure is a reference example only - following this procedure will modify your system and could lead to an outage or data loss if executed incorrectly or if your system is not compatible with this procedure. Before proceeding, make sure you fully understand each command, how it applies to your system, and its potential impact. Have a rollback plan in place in case anything unexpected occurs. If you have questions about this procedure, reach out to me via our Contact Page.

Disclaimer: The procedures and information provided in this blog post are intended for educational and informational purposes only. Hudson Cloud Systems is not responsible for any system outages, data loss, or other issues resulting from the application of these instructions. Always consult with a qualified systems administrator and thoroughly review your environment before making changes to production infrastructure.

Prerequisites and notes

Make sure you’ve got the following in place before starting:

• The host has no running VMs or templates.

• You have admin access to both vCenter and the ESXi host.

• The host has two active uplinks.

• SSH is enabled.

• Variables used in this example which will be different in your environment:

  • The host's management IP and addresses on the 192.168.100.0/24 network

  • The management vlan ID is 31

  • The virtual switch is named "EVO:RAIL Distributed Switch"

  • VMK interfaces are vmk0-4

• Always document and double check your configuration before starting.

Step 1: Prepare the Host

1. Log into vCenter

2. Confirm vSAN cluster health

3. Use vMotion to migrate all VMs off the host

4. Place the host in Maintenance Mode:

   • Right-click → Enter Maintenance Mode

   • Choose Full Data Migration

   • Run the Pre-Check

   • Confirm message: The host can enter maintenance mode. X TB of data will be moved.

   • Click Enter Maintenance Mode

Data evacuation may take several hours ⏳

Step 2: Remove the Host from the vSAN Cluster

A. SSH to the Host

Check vSAN status: esxcli vsan cluster get

You should see:

• Local node state: HEALTHY

• Maintenance Mode: ON

2. Leave the vSAN cluster: esxcli vsan cluster leave




3. Confirm the host has left: esxcli vsan cluster get

Expected output: vSAN Clustering is not enabled on this host

B. Reconfigure Networking

1. Add a temporary standard switch:

   esxcli network vswitch standard add --vswitch-name=vSwitch-mgmt-temp

2. Create a port group:

   esxcli network vswitch standard portgroup add \

   --portgroup-name=VMkernel_temp \

   --vswitch-name=vSwitch-mgmt-temp

3. Tag VLAN 31:

   esxcli network vswitch standard portgroup set \

   --portgroup-name=VMkernel_temp \

   --vlan-id=31

4. List DVPorts:

   esxcli network vswitch dvs vmware list

5. Remove vmnic0 from Distributed Switch:

   esxcfg-vswitch -Q vmnic0 -V <Port ID> "EVO:RAIL Distributed Switch"

6. Attach vmnic0 to the standard switch:

   esxcli network vswitch standard uplink add --uplink-name=vmnic0 --vswitch-name=vSwitch-mgmt-temp

C. Reassign VMkernel Interface and Routes

Next we will perform several actions in one shell command:

• Delete vmk2

• Create and add a new vmk2 to the temporary port group

• Assign IP address details to vmk2 — Set the correct IP address in the command!

• Tag vmk2 for Management traffic

• Add a default route to the default gateway

• Restart VMware services (sometimes needed)

We need to perform all of these actions as a one-liner command, as we will lose SSH connectivity as soon as vmk2 is removed.

(sh -c 'esxcli network ip interface remove --interface-name=vmk2 && \

esxcli network ip interface add --interface-name=vmk2 --portgroup-name=VMkernel_temp && \

esxcli network ip interface ipv4 set --interface-name=vmk2 --ipv4=192.168.100.xx --netmask=255.255.255.0 --type=static && \

esxcli network ip interface tag add --interface-name=vmk2 --tagname=Management && \

esxcli network ip route ipv4 add --network=default --gateway=192.168.100.1 && \

services.sh restart')

Replace 192.168.100.xx with the host’s actual IP address.

Verify the host is reachable:

ping 192.168.100.102

D. Final Uplink and Interface Cleanup

1. Find and remove vmnic1 from the Distributed Switch:

   esxcli network vswitch dvs vmware list

   esxcfg-vswitch -Q vmnic1 -V <Port ID> "EVO:RAIL Distributed Switch"

2. Remove unnecessary VMkernel interfaces:

   esxcli network ip interface remove --interface-name=vmk0

   esxcli network ip interface remove --interface-name=vmk3

   esxcli network ip interface remove --interface-name=vmk4

Step 3: Remove the Host from Inventory

1. Open the Networking tab in the vCenter web GUI




2. Under EVO:RAIL Distributed Switch:

   • Click ACTIONS > Add and Manage Hosts > Remove Hosts

   • Add the host in Maintenance Mode

   • Complete the wizard

Then:

1. Go to Hosts and Clusters

2. Right-click the host → Remove from Inventory

The host is now cleanly removed from the cluster and vCenter. ✅

Step 4: Power Off the Host

From the iDRAC or remote console:

• Select Graceful Shutdown

Wrap-Up

This step-by-step process ensures your host is decommissioned without leaving residual config or cluster instability. It's a best-practice method for wrapping up your on-prem presence after moving workloads to Azure.

Want this checklist as a PDF or automated via script? Let us know—we’d be happy to help.
